Stainless Steel 304 Bulk Grain Granule 8.0L Linear Weigher Machine Large Weight Filling

Application:

It's suitable for weighing corn, soybeans, rice, barley, wheat, buckwheat, peanuts, beans and other small granules in food industry,light industry, chemical industry in bulk weight.

Main Function & Features:

Features:

1. It's suitable for weighing material in bulk volume with high speed and high accuracy.

2. User-friendly HMI can be fast and easy take and store preselected weighing parameters for diffierent weighing range.

3. Easy operating.The operator can simply put on the bag and touch switch then the feeding, filling and unloading bags can be completed automatically finished.

4. Controller and AD module are in CAN bus communication mode, independent weighing process carried out by the AD module board, reducing controller communication time, make the weighing result feedback process more quickly.

5. Output ports use free port mode design,having a signal test function, easy to know about the equipment failure.

6. Detailed production records statistics functions.

Techanical and Character :

1.The system uses high-precision loadcell.AD converter module is with operating frequency of 400 times / s,which is high accuracy and good stability.

2.Three feeding level and special control algorithms make the weighing speed more quickly and higher accuracy.

3.Automatic entrainment structure, convenient artificial fix bags,it's safe and more efficient.

4.Material contact parts are made of stainless steel, which is especially suitable for food industry make it more health, more environmentally friendly, easy to wash and maintain.

Specifications:

Model TY-A-M92-2

Max. Weighing (one hopper) 1,000g

Accuracy x (0.5)

Min. Scale Interval 0.1g

Max. Speed 25 WPM

Hopper Volume 8.0L/10L

Control System MCU

HMI 7” color touch screen

Power Supply AC220V ±10% 50HZ/60HZ, 1KW

Packing Dimension 1,300(L)×900(W)×1,050(H)mm

Package weight 230kg
